Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-247X340
AirTAC BAQK50SAAA-247X340 Clamp-type Pin Cylinder Specifications
- Model: BAQK50SAAA-247X340
- Type: Double-acting clamp cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 340 mm (extended) / 247 mm (retracted)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 1,470 N @ 0.5 MPa (extend), 1,324 N @ 0.5 MPa (retract)
- Ambient temperature: -20℃ to 80℃
- Buffer type: Adjustable hydraulic cushion (both ends)
- Mounting style: Front flange with reinforced gussets
- Port size: G1/2 (ISO standard)
- Rod material: Hard chrome-plated steel (4Cr13)
- Tube material: Anodized aluminum alloy
- Seal type: HNBR seals with wear-resistant guide rings
- Weight: 5.8 kg (with standard accessories)
- Dimensions:
- Extended length: 793 mm
- Retracted length: 700 mm
- Mounting base: 115mm(W) × 95mm(H)
- Rod end thread: M20×1.5
- IP rating: IP54 (standard), optional IP67
Heavy-duty clamp cylinder designed for high lateral load applications, featuring an integrated pin-lock mechanism that prevents rod rotation under torque. The dual anti-vibration structure maintains positional accuracy (±0.2mm repeatability) in dynamic environments. Includes built-in magnet for position sensing compatibility with common inductive sensors (SMCRT series).
- Automotive welding fixture clamping
- Die-casting machine mold locking
- Press brake tooling positioning
- Robotic arm end-effector mounting
- Heavy conveyor gate actuation
Installation guidelines:
Use M10 class 8.8 mounting bolts with Loctite 243. Maintain 0.5-1mm clearance between clamp plate and cylinder base. Lubricate rod with ISO VG32 hydraulic oil during initial installation. Avoid side loads exceeding 300N. Requires 5μm filtered air with automatic drain.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-247X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
