Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-248X340
$467.56
Regular price
$475.06
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
BAQK50SAAA-248X340
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Titanium alloy-plated pin surfaces for enhanced wear resistance;
3. Integrated metal wiper ring on front cover effectively removes debris and chips from cylinder rod;
4. Multi-position mounting capability with quadruple-sided mounting surfaces on unit body;
5. Perimeter sensor grooves enable seamless proximity sensor integration.
Category: Clamp Pin Cylinder | Brand: AIRTAC | Series: BAQK
Installation note:
Apply 24–30 N·m torque to clamp bolts using cross-tightening sequence.
Maintain 0.5–1mm clearance between cylinder base and mounting surface for thermal expansion.
AirTAC BAQK50SAAA-248X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-248X340
- Type: Double-acting clamp-type pin cylinder
- Bore size: Ø50 mm
- Stroke: 248 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion
- Port size: 1/4" NPT (G1/8 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Standard foot-mounted with reinforced clamp bracket
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Weight: 5.8 kg ±2%
- Dimensions: 340mm(L) × 86mm(W) × 86mm(H)
- Rod end thread: M16×1.5
- Protection rating: IP54 (standard wiper design)
High-rigidity pin cylinder featuring anti-rotation clamp mechanism with 3-point load distribution. Precision honed tube and triple-lip rod seal ensure ≤0.5mm positional repeat accuracy. Requires ISO 8573-1:2010 Class 3 compressed air with 1-5μm lubricator (ISO VG32 oil recommended).
Typical Applications:
- Fixture locking in CNC machining centers
- Pallet clamping in automated production lines
- Position retention for robotic welding arms
- Mold locking in injection molding machines
- Heavy-load vertical lifting mechanisms
Installation note:
Apply 24–30 N·m torque to clamp bolts using cross-tightening sequence.
Maintain 0.5–1mm clearance between cylinder base and mounting surface for thermal expansion.
Service Cycle:
- Recommended maintenance: 3,000 km stroke or annually
- Lubrication interval: Every 1,000 cycles (minimum)
- Wear limit: Rod surface roughness ≤Ra 0.8μm
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-248X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
