Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-147X310
AirTAC BAQK50SAAA2-147X310 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA2-147X310
- Type: Double-acting clamp cylinder with integrated pin locking
- Bore size: Ø50 mm
- Stroke: 310 mm (147 indicates piston rod type code)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting: MISUMI standard clamp base (AAA-type)
- Port size: PT1/2 (G1/2 optional)
- Seal material: NBR + Polyurethane hybrid
- Rod material: Chrome-plated steel (S45C)
- Weight: 5.8 kg (±3%)
- Dimensions: 455mm(L) × 58mm(W) × 58mm(H)
- Protection rating: IP54 (standard dust/moisture resistance)
Heavy-duty clamping cylinder featuring dual safety mechanisms: mechanical pin lock and pneumatic holding force. The hexagonal barrel design prevents rotation during operation. Requires 5μm filtered air and weekly lubrication (ISO VG32 recommended). Built-in magnetic slot for position sensing (sensor not included).
- Fixture clamping in CNC machining centers
- Press tool locking systems
- Automated welding jig positioning
- Heavy component assembly stations
- Die-casting machine mold securing
Installation protocol:
Must maintain 0.02mm/m alignment tolerance during mounting.
Use torque-controlled wrench (35-40N·m for mounting bolts).
Allow 15mm clearance behind rod end for full stroke operation.
Critical note:
Engage mechanical lock before system depressurization.
Never exceed 500mm/s piston speed without external shock absorber.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-147X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
