Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-148X310
AirTAC BAQK50SAAA2-148X310 Clamp-Type Pin Cylinder Specifications
- Model Code: BAQK50SAAA2-148X310
- Series: BAQK (Heavy-Duty Clamp Cylinder)
- Bore Size: 50mm
- Stroke: 310mm
- Operating Pressure: 0.15–0.85 MPa
- Cushioning: Adjustable Air Cushion (Dual Side)
- Temperature Range: -20℃ to 80℃
- Port Size: G1/8 (Standard) or Optional NPT1/4
- Mounting Type: Front Flange with Clamp Band
- Rod Material: Chrome-Plated Carbon Steel (HCP)
- Cylinder Tube: Hard Anodized Aluminum Alloy
- End Cover: Extruded Aluminum
- Seal Material: NBR (Nitrile Rubber)
- Weight: 3.8kg ±2% (Without Accessories)
- Dimensions:
- Total Length: 548mm (Stroke + Base Structure)
- Body Diameter: 65mm
- Mounting Flange: 82mm × 82mm
- Rod End Thread: M20×1.5
High-precision clamp cylinder with anti-rotation pin mechanism, designed for applications requiring rigid fixation and precise linear motion. Features wear-resistant HCP piston rod and dual shock-absorbing cushions for smooth operation up to 3 m/s piston speed. Includes built-in magnet for position sensing compatibility.
- Robotic welding fixture clamping
- CNC machine tool workholding systems
- Automotive assembly line positioning
- Die-casting mold locking mechanisms
- Heavy-load material transfer gates
Installation Guidelines:
Maximum lateral load capacity 250N. Requires minimum 1μm filtered air supply.
Lubrication: ISO VG32 turbine oil recommended every 1,000km stroke distance.
Avoid side-mounted installations exceeding 30° angle.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-148X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
