Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-149X310
AirTAC BAQK50SAAA2-149X310 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA2-149X310
- Type: Clamp-type pin cylinder (Double-acting)
- Bore size: Ø50 mm
- Stroke: 310 mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Foot-mounted (Standard ISO 15552)
- Cushioning: Adjustable air cushion (Both ends)
- Rod material: Hard chrome-plated steel
- Seal material: NBR + PU combination
- Weight: 4.8 kg (With rod fully retracted)
- Dimensions:
- Total length (Extended): 672 mm
- Body diameter: Ø72 mm
- Mounting base: 149×50 mm (W×D)
- Rod thread: M20×1.5
- Port size: G1/8 (Standard BSPP thread)
- Protection rating: IP54 (Standard wiper design)
Heavy-duty clamp cylinder featuring dual anti-rotation pins (Ø12mm hardened steel) for precise lateral force resistance. The enhanced piston design incorporates a wear-resistant guide bushing (Lubricator-free operation possible). Features dual magnetic sensors slots compatible with AT series proximity switches.
- Robotic welding fixture positioning systems
- Die casting machine mold clamping
- Automotive assembly line pallet locking
- Heavy-load transfer mechanisms in forging presses
- Paper roll clamping in printing machinery
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. For vertical mounting,
use auxiliary rod support when stroke exceeds 250mm. Lubricate with ISO VG32
hydraulic oil if operating below -10℃.
Critical parameters:
Maximum side load capacity 550N (at full extension). Do not exceed 1.5 MPa
during cushion adjustment. Allow 30mm clearance for stroke overtravel protection.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-149X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
