Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-157X310
AirTAC BAQK50SAAA2-157X310 Clamp-type Pin Cylinder Specifications
- Model: BAQK50SAAA2-157X310
- Type: Double-acting clamp pin cylinder
- Bore size: Ø50 mm
- Stroke: 157 mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Port size: M5 (G1/8 optional)
- Mounting type: Standard foot + front flange
- Rod material: Stainless steel (SUS304)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 3.8 kg (with standard accessories)
- Dimensions: 310mm(L) × 50mm(Bore) × 82mm(H) (H includes mounting flange)
- Rod thread: M16×1.5
- Max theoretical thrust: 1570N @0.7MPa
- ISO standard: 15552 compliant
High-precision industrial cylinder featuring dual-piston clamp mechanism for zero rotation during operation. The hardened guide bushing and chromium-plated piston rod ensure wear resistance in high-cycle applications. Integrated mounting slots allow ±1mm lateral adjustment during installation.
- Precision fixturing in semiconductor wafer handling
- Vertical press-fit operations in automotive assembly
- Rotational locking in packaging turntable systems
- Workpiece positioning in CNC machining centers
- Clamping mechanisms in automated welding jigs
Installation Guidelines:1. Maintain ≤0.5mm alignment tolerance between rod and load axis
2. Use locknuts (not included) with 25-30N·m torque on rod threads
3. Lubricate with ISO VG32 hydraulic oil if operated below 0.3MPa
4. Adjust cushion screws clockwise to reduce end-impact (max 1.5 turns from fully open)
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-157X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
