Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-159X310
AirTAC BAQK50SAAA2-159X310 Clamp Type Stud Cylinder Specifications
- Model Code Breakdown:
- BAQK: Clamp type stud cylinder series
- 50: Bore size (φ50mm)
- S: Double-acting with magnetic switch
- AAA2: Special mounting configuration (front flange + rear foot)
- 159: Stroke length (159mm)
- 310: Total extended length (310mm)
- Operating pressure: 0.1–0.9 MPa
- Maximum thrust: 1,766N @0.63MPa (extend), 1,530N @0.63MPa (retract)
- Piston speed: 50–700mm/s
- Cushioning: Adjustable rubber buffer
- Port size: G1/8 (BSPP thread)
- Ambient temperature: -20℃ to 80℃
- Material:
- Barrel: Aluminum alloy with hard anodizing
- Piston rod: SUS304 stainless steel
- Seals: NBR/PU compound
- Weight: 3.45kg (dry, without accessories)
- Dimensions:
- Total length (retracted): 151mm
- Total length (extended): 310mm
- Outer diameter: φ80mm
- Mounting face width: 50mm
- Rod end thread: M16×1.5
High-rigidity clamp-type cylinder featuring integrated mounting studs for vibration-resistant installation. The T-slot design enables 360° adjustable mounting positions. Equipped with magnetic piston for position sensing compatibility (sensor not included). Optimized for heavy-duty cycles with 50km minimum service life.
- Precision alignment in automated welding fixtures
- Vertical lifting mechanisms for conveyor transfers
- Clamping devices in CNC machine tool changers
- Position locking in automotive assembly jigs
- Material press-fit operations in electronics manufacturing
Installation guidelines:
Use M12×1.25 mounting bolts with 40-50N·m torque. Maintain 0.5mm minimum clearance between magnetic switch and rod. Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 200N.
Critical note:
Not suitable for rotational applications. Maximum permissible rod end play: ±1.5°. Always install rod protection bellows in environments with particulate contamination.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-159X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
