Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-179X360
AirTAC BAQK50SAAA2-179X360 Clamp-Type Stud Cylinder Specifications
- Model: BAQK50SAAA2-179X360
- Type: Double-acting clamp cylinder with integrated stud
- Bore size: Ø50 mm
- Stroke: 360 mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Mounting type: Fixed stud (non-rotating) with reinforced clamp brackets
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR + PU hybrid seals
- Weight: 4.8 kg (±2%)
- Dimensions: 179mm (mounting length) × 85mm (max width) × 112mm (height with brackets)
- ISO standard: 6432 compliant
- Protection rating: IP54 (standard), IP67 optional
High-rigidity clamp cylinder designed for precision positioning in heavy-duty applications. Features triple-sealed piston rod protection and anti-vibration stud locking mechanism. The 3-stage buffer system minimizes end-impact noise below 75dB. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
- Automotive welding fixture positioning
- Die-casting machine core-pulling mechanisms
- Heavy conveyor gate actuators
- Semiconductor wafer handling robots
- Press tooling alignment systems
Installation note:
Apply 24-28 N·m torque to clamp screws during mounting.
Requires weekly inspection of stud locking collar (P/N: BAQK-LC50)
in high-cycle applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-179X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
