Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-197X360
AirTAC BAQK50SAAA2-197X360 Clamping Pin Cylinder Specifications
- Model: BAQK50SAAA2-197X360
- Type: Double-acting clamping pin cylinder
- Bore size: Ø50 mm
- Stroke: 197 mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Mounting type: Front flange with reinforced base (SAAA2 code)
- Rod end: External M20x1.5 male thread
- Cushioning: Adjustable air cushion at both ends
- Ambient temperature: -10℃ to 70℃
- Seal material: Polyurethane (PU) with wear-resistant ring
- Weight: 4.8 kg ±2%
- Dimensions:
- Body length: 360 mm (excluding rod)
- Extended length: 360 + 197 = 557 mm
- Width (flange base): 90 mm
- Height (including mounting): 125 mm
- Port size: G1/8 (ISO228 standard)
- Anti-rotation accuracy: ±0.5°
- ISO standard: 15552 compliant
High-rigidity clamping cylinder featuring integrated anti-rotation pins and reinforced mounting structure. The hexagon-shaped body prevents rotation during operation, making it ideal for precision positioning tasks. Special chromium-plated piston rod resists side loads up to 30% of maximum thrust capacity.
- Robotic arm end-effector positioning
- CNC machine tool fixture clamping
- Automated welding jig systems
- Palletizing robot joint locking
- High-precision optical alignment devices
Installation tip:
Apply 32# hydraulic oil for initial lubrication. Ensure clamp pins engage fully with mating parts
before pressure application. Maximum side load capacity reduces by 15% when operated above 60℃.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-197X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
