Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-198X360
AirTAC BAQK50SAAA2-198X360 Clamp-Type Pin Cylinder Specifications
- Series: BAQK (High Rigidity Clamp Series)
- Bore size: 50mm
- Stroke: 360mm
- Rod diameter: 20mm (chrome-plated)
- Operating pressure: 0.05–1.0 MPa
- Mounting type: Front flange with reinforced clamp brackets
- Cushioning: Adjustable air cushion + shock absorber
- Port size: G3/8 (dual ports)
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (anodized finish)
- Seal type: NBR + special wear-resistant ring
- Weight: 3.8kg (excluding accessories)
- Dimensions: 198mm (retracted length) × 135mm (width) × 72mm (height)
- Rod end: Female thread M10×1.25
- Protection class: IP54 (standard dust/water resistance)
- Optional sensors: Magnetic switch compatible (slot for mounting)
A heavy-duty clamp cylinder engineered for precision positioning and high lateral load resistance. Features dual anti-rotation pins (Ø8mm hardened steel) integrated into the clamp brackets, preventing piston rod rotation under torque loads. The enhanced guide structure ensures ≤0.2mm lateral play during full stroke operation.
- Automated welding fixture clamping systems
- Press machine tool positioning
- Die-casting mold locking mechanisms
- Heavy component alignment in assembly lines
- Pallet locking in CNC machining centers
Installation note:
Requires 0.3-1.0 MPa filtered air with auto-lubrication (ISO VG32 recommended).
Mounting surface flatness must be within 0.1mm/m. Avoid side loads exceeding 200N
without additional guide mechanisms. Perform stroke-end cushion adjustment
during commissioning using the hex wrench (included).
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-198X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
