Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA2-248X360
AirTAC BAQK50SAAA2-248X360 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA2-248X360
- Type: Double-acting clamp pin cylinder
- Bore size: 50mm
- Stroke: 248mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front/rear flange mounting (ISO 15552 standard)
- Body material: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP40
- Weight: 3.8kg (excluding accessories)
- Dimensions: 360mm(L) × 100mm(W) × 100mm(H) (full extension)
- Rod end thread: M16×1.5
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (DIN standard VDL oil)
High-precision clamp cylinder featuring integrated mechanical locking mechanism for mid-stroke position holding. The corrosion-resistant design incorporates dual guide rods for enhanced lateral load capacity (max 120N·m moment tolerance). Requires 5μm filtered air with oil mist lubrication recommended for high-cycle applications.
- Automated assembly line positioning fixtures
- Material handling equipment with intermediate stops
- Precision welding jigs requiring vibration resistance
- Press tooling with mid-position workpiece retention
- Packaging machinery with sequential clamping actions
Installation note:
Ensure proper alignment of guide rods within ±0.2mm tolerance.
Apply thread lock (medium strength) to mounting bolts during assembly.
Perform 10-15 dry cycles before load operation.
- Maintain air supply dew point at least 5℃ below ambient temperature
- Limit side load to ≤10% of maximum thrust capacity
- For vertical mounting: Use counterbalance valve when holding >5kg loads
- Re-lubricate every 500,000 cycles under normal operating conditions
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA2-248X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
