Airtac CM3HS Selector Mechanical Valve CM3HS05B
$21.16
Regular price
$28.66
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3HS05B
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. CM3B, CM3L, CM3V, and CM3R series require external mechanisms to provide actuation force for valve switching, suitable for position sensing or limit switch applications;
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
Maintenance protocol:
Lubricate pivot points every 50,000 cycles using ISO VG32 pneumatic oil.
Avoid side-loading during manual operation - apply force perpendicular
to actuator button. Maximum allowable misalignment: 2°.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS05B Selector Mechanical Valve Technical Details
- Model: CM3HS05B (5-port selector type)
- Valve type: 5/2-way mechanical actuation (spring return)
- Port thread: G1/8 (BSPP) with NPT optional
- Operating pressure range: 0.1–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation force: 3.5N minimum manual override
- Weight: 215g ±5g (with fittings)
- Dimensions: 56mm(L) × 34mm(W) × 72mm(H)
- Body material: Aluminum alloy (hard anodized)
- Seal compatibility: NBR/FKM/EPDM (standard: NBR)
- Temperature tolerance: -20℃ to 80℃ (with silicone seals up to 120℃)
- Vibration resistance: ≤10–55Hz with 1.5mm amplitude
- Mounting: Panel mount with M4 screws (2x)
High-cycle mechanical valve featuring dual-position memory function and manual override. Optimized for precise directional control in harsh environments with IP67-rated dust/water protection. Internal flow path geometry reduces pressure drop by 18% compared to previous generations.
Industrial Applications:
- Pneumatic cylinder sequencing in assembly lines
- Textile machinery clutch engagement systems
- Food processing equipment with frequent position switching
- Mobile hydraulic pilot controls (construction equipment)
- Semiconductor wafer handling vacuum/pressure systems
Maintenance protocol:
Lubricate pivot points every 50,000 cycles using ISO VG32 pneumatic oil.
Avoid side-loading during manual operation - apply force perpendicular
to actuator button. Maximum allowable misalignment: 2°.
| Property | Property Value |
|---|---|
| sku | CM3HS05B |
| Position | 3-Port 2-Position |
| Port Size | M5 |
