Airtac CM3HS Selector Mechanical Valve CM3HS06-P4
$9.73
Regular price
$17.23
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CM3HS06-P4
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. CM3B, CM3L, CM3V, and CM3R series require external mechanisms to provide actuation force for valve switching, suitable for position sensing or limit switch applications;
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
Installation protocol:
Apply 24-28 N·m torque during port connection. Lubricate O-rings with
silicone grease (viscosity grade VG10). For horizontal mounting,
install drain cup at R port. Max alignment tolerance: ±1.5°.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS06-P4 Selector Mechanical Valve Technical Details
- Model: CM3HS06-P4
- Type: 3-position selector valve (Manual mechanical operation)
- Port configuration: 6 ports (P, A, B, T1, T2, R)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Actuation force: ≤50N lever operation
- Seal material: HNBR (Hydrogenated Nitrile) with metal body
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Weight: 820g ±2% (1.81 lbs)
- Dimensions: 98mm(L) × 48mm(W) × 78mm(H)
- Mounting: Direct panel mounting with M5 screws
- Port thread depth: 12mm (with O-ring seal)
- Hysteresis: ≤0.02 MPa
Heavy-duty manual selector valve with positive center position, featuring dual exhaust ports (T1/T2) for complex pneumatic circuit control. The chrome-plated brass construction ensures corrosion resistance in humid environments. Includes dust-resistant lever mechanism with tactile position feedback.
Industrial Applications:
- Production line mode selection systems
- Hydraulic/pneumatic circuit manual override
- Material handling equipment direction control
- Test bench pressure routing
- Emergency stop system integration
Installation protocol:
Apply 24-28 N·m torque during port connection. Lubricate O-rings with
silicone grease (viscosity grade VG10). For horizontal mounting,
install drain cup at R port. Max alignment tolerance: ±1.5°.
Critical Note:
Requires weekly manual cycling if unused for extended periods to
prevent seal adhesion. Not compatible with phosphate ester fluids.
| Property | Property Value |
|---|---|
| sku | CM3HS06-P4 |
| Position | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
