Airtac CM3HS Selector Mechanical Valve CM3HS08Y
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with diversified actuator head configurations for optimal adaptability in varied working conditions;
3. Poppet valve design ensures excellent sealing performance, smooth directional switching, and oil-free operation;
4. Multiple mounting orientations enable flexible installation and system integration;
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for extended service life and enhanced reliability;
6. CM3PMS and CM3PMX series are equipped with metal protective covers to safeguard pushbuttons against accidental actuation and mechanical impacts, ensuring fail-safe operation.
Category: Mechanical Valves , Brand: Airtac , Series: CM3HS
AirTAC CM3HS08Y Selector Mechanical Valve Technical Details
- Model: CM3HS08Y
- Type: 3-position selector valve (Mechanical detent)
- Port configuration: 5 ports (P, A, B, R1, R2)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa
- Max flow rate: 850 L/min (ANR)
- Actuation force: ≤3.5 N
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (up to 120℃ intermittent)
- Temperature range: -10℃ to 80℃ (continuous operation)
- Weight: 280g ±5g
- Dimensions: 58mm(L) × 34mm(W) × 74mm(H)
- Mounting: ISO 15407-1 compliant sub-base
- Lubrication: Pre-lubricated (do not add oil)
Manual override valve with positive center position locking, featuring a wear-resistant roller lever mechanism for precise mid-stroke positioning. The dual exhaust design (R1/R2 ports) enables independent return flow management. Hard anodized body resists chemical corrosion in harsh environments.
- Clamping fixture position control in CNC machining centers
- Emergency stop override in automated assembly lines
- Pneumatic cylinder mid-position locking systems
- Material handling equipment with manual intervention requirements
- Test bench pneumatic circuit configuration
Installation guidelines:
Mount lever axis perpendicular to operator's motion direction.
Apply silicone-free grease to the shaft seal annually in high-cycle applications (>500k operations/year).
Maximum lateral force on lever: 15N.
