Airtac CM3PF Flat Push Button Mechanical Valve CM3PF05B
1. CM3B, CM3L, CM3V, and CM3R series require external force for directional switching, suitable for position detection or limit switch applications.
2. CM3PF, CM3PM, CM3PMS, CM3PMX, CM3PL, CM3PP, CM3HS, CM3HD, and CM3Y series feature manual operation with multi-configuration actuator heads for diverse operational conditions.
3. Shut-off type structure ensures excellent sealing performance, responsive direction switching, and lubrication-free operation.
4. Multi-position mounting capability enables flexible installation configurations.
5. CM3L, CM3V, CM3R, and CM3Y series incorporate metal actuator heads for enhanced durability and operational stability.
6. CM3PMS and CM3PMX series integrate metal protective covers to safeguard button caps and prevent accidental activation from external forces.
Category: Mechanical Valves | Brand: AirTAC | Series: CM3PF
AirTAC CM3PF05B Flat-Head Push Button Mechanical Valve Specifications
- Model: CM3PF05B
- Type: 3-position (5-port) closed center mechanical valve
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 350 NL/min (ANR)
- Operating temperature: -5℃ to 60℃ (with NBR seals)
- Body material: Nickel-plated brass
- Spool type: Metal piston with wear-resistant guide
- Actuation force: 30N ±5N
- Weight: 180g ±5g
- Dimensions: 38mm(L) × 38mm(W) × 42mm(H)
- Port thread depth: 10mm engagement
- Hysteresis: ≤0.02 MPa
- Leakage: <3 bubbles/min (ISO Standard 6952)
- Cycle life: 2 million operations (minimum)
Manual override valve with tactile feedback, featuring dual O-ring sealing and anti-rotation stem design. The chrome-plated brass construction resists corrosion in humid environments. Requires manual reset after actuation, with positive center position locking mechanism. Compatible with ISO VDMA and CETOP mounting patterns.
- Emergency stop systems in pneumatic circuits
- Manual mode override in automated assembly lines
- Jig and fixture control in CNC machining centers
- Material handling system bypass controls
- Educational pneumatic training equipment
- Textile machinery manual intervention points
Installation note:
Apply thread sealant only on male ports, avoid overtightening (max 1.5Nm torque).
For vertical mounting, position exhaust ports downward to prevent debris accumulation.
Lubricate spool monthly with ISO VG32 hydraulic oil in high-cycle applications.
