Airtac CPV10S Integrated Manifold Valve CPV10SJ03B10F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B10F Technical Details
- Model: CPV10SJ03B10F (Modular Stackable Design)
- Type: 5/3-way solenoid valve with double solenoid control
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage options: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Flow capacity: 750 Nl/min (Cv=1.3 at 0.5MPa)
- Response time: ≤15ms (exhaust to actuation)
- Weight: 0.68 kg (1.5 lbs) ±2%
- Dimensions: 60mm(W) × 25mm(H) × 110mm(L)
- Seal material: Heat-resistant HNBR (-10℃ to 120℃)
- Ambient temperature: -10℃ to 50℃ (non-freezing)
- Power consumption: 2.5W (DC) / 4.5VA (AC)
- Protection rating: IP67 (dust/water resistant)
- Mounting: ISO 15407-1 compliant manifold interface
- Port thread depth: 12mm (minimum engagement)
High-density modular valve featuring dual-coil latching design for energy-efficient operation. Incorporates a zero-leakage spool structure with self-lubricating guides, optimized for multi-station pneumatic systems requiring sequential control. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- Multi-axis robotic gripper systems
- Beverage canning line diverters
- Plastic injection molding machine clamps
- Automotive assembly line fixtures
- Semiconductor wafer handling robots
Installation protocol:
Stacking alignment requires 0.5-0.8Nm torque on manifold screws.
Maintain 20mm clearance below valve for condensate drainage.
Use shielded cables for EMI-sensitive environments.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B10F |
