Airtac CPV10S Integrated Manifold Valve CPV10SJ03B14F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B14F Technical Specifications
- Full model code: CPV10SJ03B14F
- Valve type: 5/3-way closed center (electro-pneumatic pilot operated)
- Port configuration: 4 ports (P, A, B, R) + 2 exhausts
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–0.9 MPa (21.7–130.5 PSI)
- Max flow capacity: Cv 0.42 / Effective area 1.2mm²
- Voltage variants: DC24V (±10%), DC12V (customizable)
- Coil power: 1.6W (standard), 1.8W (high surge version)
- Weight: 480g ±2% (including manifold base)
- Dimensions: 56mm(W) × 54mm(H) × 27mm(D) (single valve stack)
- Body material: Anodized aluminum alloy (ALDC12)
- Seal material: Heat-resistant NBR (-5℃ to 80℃)
- Response time: ≤25ms (exhaust to actuation)
- Protection class: IP67 (coil), IP40 (valve body)
- Mounting type: ISO 15407-1 compliant manifold system
Modular pneumatic control valve with integrated silencer and speed controller, featuring multi-position memory function for mid-position holding applications. The hardened aluminum body with anti-vibration design ensures stable operation in high-cycle environments (up to 5 million cycles). Includes built-in surge protection and polarity reversal safeguard.
- Robotic gripper pressure regulation in assembly lines
- Clamping sequence control for CNC fixtures
- Packaging machine cylinder synchronization
- Textile machinery tension control systems
- Battery module compression testing equipment
Installation protocol:
Requires 0.5Nm torque for manifold stacking. Maintain minimum 15mm
clearance below exhaust ports for proper airflow. Use M3×8 stainless
steel screws for panel mounting (not included).
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B14F |
