Airtac CPV10S Integrated Manifold Valve CPV10SJ03B16F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B16F Technical Specifications
- Model: CPV10SJ03B16F
- Valve type: 5-port 3-position closed center (Integrated manifold base)
- Port configuration: 5/3 closed center (ISO symbol: 5/3 NC)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage: DC24V ±10% (Coil class F insulation)
- Power consumption: 1.2W (Standard), 0.6W (Power-saving mode)
- Response time: ≤15ms (Energize), ≤20ms (De-energize)
- Flow rate: 750 l/min (ANR, at 0.5 MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Temperature range: -5℃ to 60℃ (No freeze)
- Protection rating: IP67 (Dust tight & protected against immersion)
- Weight: 298g ±5g
- Dimensions: 40mm(W) × 30mm(H) × 60mm(D) (Manifold mounting surface)
- Port spacing: 10mm (Between adjacent valves in manifold)
High-density integrated valve with dual-coil latching design, featuring gold-plated terminals for enhanced conductivity. The modular structure allows cascade connection of up to 16 units. Includes built-in surge protection and LED status indicator. Requires ISO 8573-1:2010 Class 3.4.2 compressed air (40μm filtration, -20℃ dew point).
- Multi-axis pneumatic actuator synchronization systems
- Battery production line clamping controls
- Semiconductor wafer handling robots
- Automated textile machinery tension control
- High-cycle packaging machine diverters
Installation guidelines:
Maximum allowable manifold bending moment 3.5N·m. Use M3×8 mounting screws with 0.49–0.68N·m torque.
Maintain 50mm clearance below valve for maintenance access. Avoid magnetic field interference sources within 300mm.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B16F |
