Airtac CPV10S Integrated Manifold Valve CPV10SJ03B22F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B22F Technical Specifications
- Model: CPV10SJ03B22F
- Type: 5/3-way solenoid operated (center closed position)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Flow rate: 750 L/min (ANR) at 0.5 MPa
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 152mm(L) × 44mm(W) × 47mm(H)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE coating
- Temperature range: -5℃ to 60℃ (operating fluid/ambient)
- Power consumption: 2.5W (DC), 4.5VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-density integrated valve combining multiple functions in a single manifold block. Features low power consumption design with surge protection circuitry and LED status indicator. The corrosion-resistant aluminum body with hard anodized finish ensures durability in harsh environments. Requires ISO 8573-1 class 3 (40μm) filtered compressed air with oil mist lubrication recommended.
- Multi-axis pneumatic actuator synchronization systems
- Automated assembly line clamping/positioning units
- Textile machinery tension control modules
- Beverage filling machine flow control clusters
- Semiconductor wafer handling vacuum/pressure switching
Installation guidelines:
Mount horizontally with manifold surface facing downward to prevent debris accumulation.
Use flexible tubing for the first 300mm of connections to reduce vibration stress.
Perform weekly manual cycling during standby periods exceeding 72 hours.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B22F |
