Airtac CPV10S Integrated Manifold Valve CPV10SJ03B6F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Manifold Valve CPV10SJ03B6F Specifications
- Model: CPV10SJ03B6F
- Type: 5/3-way normally closed (electro-pneumatic pilot operated)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including manifold base)
- Dimensions: 70mm(L) × 35mm(W) × 85mm(H)
- Seal material: NBR/FKM (optional high-temp seals)
- Temperature range: -5℃ to 60℃ (with FKM seals: -10℃ to 80℃)
- Power consumption: ≤2.5W (DC)/≤3.5VA (AC)
- Flow rate: 650 NL/min (Cv=1.2 at 0.5MPa)
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (coil)/IP65 (valve body)
- Port thread depth: 10mm (minimum engagement)
High-density integrated manifold valve with aluminum alloy body, designed for multi-station pneumatic control systems. Features zero leakage design in neutral position and surge protection circuitry. Requires ISO 8573-1:2010 Class 3 compressed air (max 50mg/m³ oil content). Includes built-in manual override and LED status indicator.
- Multi-axis pneumatic actuator synchronization
- Semiconductor wafer handling robots
- Bottle capping machine sequencing
- Automated test equipment (ATE) fixture control
- Cleanroom automation systems
Installation note:
Mount on ISO 4400 standard manifold base (CPV10-MB series). Maintain 20mm
clearance below valve for heat dissipation. Use flexible tubing for
vibration isolation in high-cycle applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B6F |
