Airtac CPV10S Integrated Manifold Valve CPV10SJ03B8F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03B8F Technical Specifications
- Model: CPV10SJ03B8F (CPV10S series)
- Valve type: 5-port 3-position integrated solenoid valve
- Port configuration: P, A, B, R, S (ISO 5599-1 standard)
- Port size: G1/8 (Rc1/8 optional)
- Operating pressure: 0.15–0.7 MPa (21.7–101.5 PSI)
- Voltage: DC24V ±10% (coil class F insulation)
- Power consumption: 2.2W (steady state), 5.5VA (inrush)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Flow rate: 750 NL/min (at 0.5 MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for high temp resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Weight: 450g ±3% (including manifold base)
- Dimensions: 58mm(W) × 35mm(H) × 102mm(L)
- Manual override: Built-in emergency push button
- Port alignment: 25mm center-to-center spacing
Modular pneumatic control solution combining valve, manifold, and solenoid into a single unit. Features dual-pressure operation capability with internal pilot check valves. Optimized for multi-station automation systems requiring synchronized actuation. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size, -20℃ pressure dew point).
- Multi-axis robotic end effectors (pick-and-place systems)
- Plastic injection molding machine ejectors
- CNC tool changers with dual-clamp verification
- Bottle filling line diverters
- Automated test equipment with sequenced air logic
Installation protocol:
Mount on flat surface with M4 screws (max 0.5Nm torque). Maintain ≥15mm
clearance below manifold for tubing. Use Loctite 243 on manifold joints.
Perform 50% duty cycle during first 100 activations for seat conditioning.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03B8F |
