Airtac CPV10S Integrated Manifold Valve CPV10SJ03F10F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F10F Technical Details
- Model: CPV10SJ03F10F
- Type: 3-position, 5-way integrated solenoid valve (Double solenoid)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.7 MPa (21.7–101.5 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (including manifold base)
- Dimensions: 54mm(L) × 35mm(W) × 76mm(H)
- Flow coefficient (Cv): 1.2
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤30ms (excitation), ≤50ms (reset)
- Protection rating: IP65 (coil part)
- Port thread depth: 12mm (minimum engagement)
Modular pneumatic control solution combining valve and manifold, featuring zero leakage design with dual-pressure holding capability. The aluminum alloy body ensures heat dissipation and vibration resistance. Includes manual override and position-indication LED. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Multi-axis industrial robot end effectors
- High-cycle packaging machine clamping systems
- CNC machine tool fixture sequencing
- Beverage filling line diverters
- Lithium battery production pneumatic circuits
Installation guidelines:
Mount on ISO standard manifold using M4 mounting screws (2.5Nm torque limit).
Maintain 15mm clearance below valve for tubing access. Use shock-absorbing
brackets in high-vibration environments. Pre-charge system to 0.3MPa before
initial activation.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F10F |
