Airtac CPV10S Integrated Manifold Valve CPV10SJ03F12F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F12F Technical Details
- Model: CPV10SJ03F12F
- Type: 5/2-way single solenoid valve (spring return)
- Port configuration: 5 ports (P, A, B, EA, EB) / 2 positions
- Port size: PT1/8 (ISO G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 0.35 (at 7 bar) / Effective area 4.2 mm²
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Seal material: Heat-resistant NBR (Nitrile) with PTFE piston ring
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Weight: 320g ±5% (with coil)
- Dimensions: 54mm(W) × 32mm(H) × 78mm(L)
- Protection class: IP67 (coil), IP40 (valve body)
- Electrical connection: DIN43650 Form A connector
- Lubrication: Pre-lubricated (maintenance-free for 10M cycles)
High-density integrated valve featuring dual-pressure control capability and shock-resistant design. The optimized flow path reduces pressure drop by 18% compared to previous generations. Equipped with manual override and position indicator. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.3 quality.
- Multi-axis pneumatic manipulators in assembly lines
- High-cycle molding machine ejector systems
- Automated test equipment with position feedback
- Textile machinery tension control mechanisms
- Battery production handling systems
Installation guidelines:
Mount horizontally with manifold using M4×12 screws (1.2-1.5N·m torque).
Maintain 50mm clearance below for tubing. Perform monthly exhaust port
cleaning in dusty environments. Not compatible with silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F12F |
