Airtac CPV10S Integrated Manifold Valve CPV10SJ03F20F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F20F Technical Specifications
- Model: CPV10SJ03F20F (CPV10S series)
- Type: 3-position closed center, 5-way pilot-operated solenoid valve
- Port configuration: 5 ports (P, A, B, EA, EB)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Flow capacity: 750 L/min (ANR) at 0.5 MPa
- Response time: ≤50 ms (excitation), ≤70 ms (de-excitation)
- Weight: 520g ±5% (including manifold base)
- Dimensions: 98mm(L) × 82mm(W) × 54mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) for enhanced oil resistance
- Temperature range: -5℃ to 60℃ (no freezing)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Protection rating: IP67 (dustproof & temporary immersion protection)
- Endurance: ≥10 million cycles (JIS B8377 standard)
Modular pneumatic control solution with integrated manifold base, featuring zero pressure differential operation capability. The staggered coil design prevents mutual magnetic interference in multi-valve configurations. Includes manual override and position indicator. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size).
- Multi-axis pneumatic actuator synchronization in CNC machines
- Plastic injection molding machine clamp control
- Automated material handling systems with position feedback
- Semiconductor wafer handling vacuum/pressure switching
- Food packaging lines requiring washdown compatibility
Installation protocol:
Mount on ISO 5599/1 standard manifold using M5 mounting screws (2.0N·m torque limit).
Maintain 15mm clearance below valve for heat dissipation. Use surge absorbers when
controlling capacitive loads above 0.1F.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F20F |
