Airtac CPV10S Integrated Manifold Valve CPV10SJ03F22F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F22F Technical Specifications
- Model: CPV10SJ03F22F (Series CPV10S)
- Valve type: 5/3-way solenoid operated (center closed position)
- Port configuration: 10 ports (P, A, B, EA, EB, R1, R2, S1, S2, S3)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa
- Voltage variants: DC24V (±10%), AC220V 50/60Hz
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Max flow rate: 700 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (reset)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Protection class: IP67 (dustproof & temporary immersion resistant)
- Weight: 680g ±2% (including manifold base)
- Dimensions: 52mm(W) × 60mm(H) × 127mm(L) (manifold mounting surface)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤10% of rated voltage
Modular manifold-mounted valve featuring multi-position control with integrated silencer and surge suppression. The CPV10SJ03F22F employs a pilot-operated design with dual coil protection diodes, enabling continuous duty cycle operation. Its aluminum alloy body with hard anodized treatment resists chemical corrosion in harsh environments. The optimized flow path reduces pressure drop by 18% compared to previous generations.
- Multi-axis pneumatic actuator control in CNC machinery
- Sequential clamping systems in injection molding
- Automated material handling systems with position feedback
- Electronics assembly line vacuum/pressure switching
- Packaging machine multi-stage cylinder control
Installation protocol:
Mount on ISO 5599-1 compliant manifold using M4 mounting screws (2.5Nm torque limit).
Maintain 0.5m minimum clearance from high-frequency inverters.
Use 5μm filtered air with automatic drain. Lubrication not required.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F22F |
