Airtac CPV10S Integrated Manifold Valve CPV10SJ03F4F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F4F Technical Details
- Model: CPV10SJ03F4F (ISO 15407-1 compliant)
- Valve type: 5/3-way closed center, double solenoid
- Port configuration: 10 ports (5 positions, 3 states)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 850 L/min (ANR) at 0.5 MPa
- Response time: ≤35ms (exhaust to center position)
- Weight: 1.25 kg (2.76 lbs) with connectors
- Dimensions: 105mm(L) × 54mm(W) × 92mm(H)
- Seal materials: HNBR main seals with FKM backup rings
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection class: IP67 (dust/water resistant)
- Endurance: ≥10 million cycles (JIS B8377 tested)
High-density modular valve featuring multi-position control with integrated silencer and surge suppression. The stacked design enables centralized pneumatic control with minimized pressure drop (ΔP≤0.02MPa at max flow). Includes manual override and position sensing compatibility via built-in M8 connector slots.
- Multi-axis CNC machine tool changers
- Automated assembly line clamping systems
- Plastic injection molding machine actuators
- Lithium battery production vacuum circuits
- Robotic welding station safety interlocks
Maintenance protocol:
Lubricate spool every 5,000 operating hours using ISO VG32 turbine oil.
Use 5-40μm filtration with automatic drain. Avoid mounting near high-frequency
vibration sources (>200Hz) to prevent coil loosening.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F4F |
