Airtac CPV10S Integrated Manifold Valve CPV10SJ03F6F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F6F Technical Details
- Model: CPV10SJ03F6F
- Type: 5/3-way closed center (pilot-operated)
- Port configuration: 5 ports (P, A, B, EA, EB) / 3 positions
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.1–0.8 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 600g ±2% (including coil)
- Dimensions: 80mm(L) × 50mm(W) × 100mm(H)
- Seal materials: HNBR (Hydrogenated Nitrile) standard (FKM available for high-temp)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Flow capacity: 1200 NL/min (ANR at 0.5MPa)
- Response time: ≤30ms (at rated voltage)
- Protection class: IP67 (coil protection)
- Mounting style: ISO 15407-1 compliant subplate
High-density integrated manifold valve with centralized control capability, featuring aluminum alloy body with hard anodized finish for corrosion resistance. The dual solenoid configuration enables precise mid-position control in pneumatic circuits. Optimized flow paths reduce pressure drop by 18% compared to previous generation models.
- Multi-axis pneumatic actuator synchronization systems
- Automated assembly line clamping/unclamping sequences
- Plastic injection molding machine core-pull mechanisms
- Material handling equipment with position hold requirements
- Test bench pressure regulation systems
Installation guidelines:
Use M5 mounting screws with 0.8-1.2Nm torque. Maintain 20mm clearance above valve for heat dissipation.
Always install downstream filter (5μm or finer) with automatic drain. Lubricated air (ISO VG32) recommended
for extended seal life. Maximum allowable lateral piping load: 15N.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F6F |
