Airtac CPV10S Integrated Manifold Valve CPV10SJ03F8F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ03F8F Technical Specifications
- Full Model Code: CPV10SJ03F8F
- Valve Type: 5/3-way closed center (dual solenoid pilot-operated)
- Port Configuration: 10 ports (5 working, 3 positions)
- Port Size: G1/8 (BSPP) with ISO 228-1 standard threads
- Operating Pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage Options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power Consumption: 2.2W (DC24V), 3.5VA (AC)
- Flow Capacity: 750 NL/min (ANR) at 0.5 MPa
- Response Time: ≤15ms (energize), ≤20ms (de-energize)
- Seal Material: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Body Material: Anodized aluminum alloy (A6063-T5)
- Temperature Range: -5℃ to 60℃ (operating fluid), -20℃ to 80℃ (storage)
- Protection Rating: IP67 (coil), IP40 (valve body)
- Weight: 320g ±5g (including connectors)
- Dimensions: 78mm(L) × 34mm(W) × 62mm(H) (excluding fittings)
- Mounting: Sub-base compatible with ISO 15407-2 standard
High-density integrated valve combining manifold and solenoid valves in a space-saving design. Features zero leakage design with redundant sealing system and shock-resistant coil construction. The F8F variant includes manual override buttons with position indicators and surge protection circuitry. Requires 5μm filtered lubricated air (ISO 8573-1 class 4.4.3).
- Multi-axis pneumatic actuator synchronization in assembly robots
- Plastic injection molding machine clamp control
- CNC tool changer positioning systems
- Food processing vacuum/pressure cycling systems
- Lithium battery formation equipment gas control
Installation Guidelines:
Maintain 15mm clearance above valve for heat dissipation. Use M4×12 stainless steel screws
(1.2-1.5N·m torque). Perform port alignment within ±0.5mm tolerance during manifold connection.
Recommended maintenance: 10,000km cycle lubrication for continuous operation.
Critical Note:
Avoid using silicone-based lubricants - incompatible with HNBR seals.
Maximum allowable vibration: 49m/s² (5G) at 10-2000Hz frequency range.
| Property | Property Value |
|---|---|
| sku | CPV10SJ03F8F |
