Airtac CPV10S Integrated Manifold Valve CPV10SJ04B10F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B10F Technical Specifications
- Model: CPV10SJ04B10F
- Series: CPV10S Modular Valve System
- Valve type: 5/3-way double solenoid (closed center)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–1.0 MPa (21.7–145 psi)
- Voltage variants: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Coil insulation class: Class F (155°C)
- Weight: 680g (1.5 lbs) with manifold base
- Dimensions: 52mm(W) × 30mm(H) × 120mm(L)
- Flow capacity: 850 l/min (Cv=1.2 at 0.5MPa)
- Seal material: HNBR (Hydrogenated Nitrile) for oil/fuel resistance
- Temperature range: -10℃ to 80℃ (with silicone seals optional to -20℃)
- Response time: ≤25ms (exhaust to center position)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 10mm (minimum engagement)
Modular pneumatic control valve featuring multi-position functionality for complex circuit designs. The CPV10S series employs a unique pilot piston structure with wear-resistant anodized aluminum body, optimized for high-cycle industrial environments. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.4.2 air quality standard compliance.
- Multi-axis robotic end effector control
- Plastic injection molding machine clamp systems
- Automated assembly line positioning fixtures
- CNC machine tool chuck actuators
- Bottle filling station divert mechanisms
Installation guidelines:
Mount on ISO standard manifold base (CPV10-MB series recommended) with 0.1-0.2Nm tightening torque.
Maintain ambient temperature below 60℃ with 20mm clearance for heat dissipation.
Use anti-vibration washers in high-frequency cycling applications (>5Hz).
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B10F |
