Airtac CPV10S Integrated Manifold Valve CPV10SJ04B12F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B12F Technical Specifications
- Model: CPV10SJ04B12F
- Type: 4-position 3-way integrated manifold valve (pilot-operated)
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage options: DC24V (±10%), AC110V 50/60Hz, AC220V 50/60Hz
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Weight: 1.25 kg (2.76 lbs) with manifold
- Dimensions: 135mm(L) × 42mm(W) × 74mm(H)
- Manifold material: Anodized aluminum alloy
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 60℃ (14℉ to 140℉)
- Power consumption: ≤2.5W per solenoid
- Response time: ≤15ms (on/off cycle)
- Protection rating: IP67 (dust/water resistant)
- Mounting pattern: ISO 15407-1 compliant
High-density modular valve system with integrated manifold and silencer, featuring anti-vibration design for stable operation in high-cycle applications. The stacked configuration allows centralized control of multiple actuators with optimized airflow paths. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Multi-axis pneumatic robotic systems
- Beverage canning line control clusters
- Automotive assembly line fixture controls
- High-speed packaging machinery sequencing
- Semiconductor wafer handling equipment
Installation note:
Mount on vibration-damped surfaces using M5 mounting screws (torque ≤1.2N·m).
Maintain 20mm clearance above manifold for heat dissipation. Use shielded cables
for solenoid connections in EMI-sensitive environments.
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B12F |
