Airtac CPV10S Integrated Manifold Valve CPV10SJ04B16F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B16F Technical Specifications
- Model: CPV10SJ04B16F
- Type: 4-station modular solenoid valve manifold (5/3-way)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Flow capacity: 750 NL/min (Cv=1.3)
- Response time: ≤15ms (actuation), ≤20ms (release)
- Weight: 520g (1.15 lbs) with all solenoids installed
- Dimensions: 120mm(L) × 54mm(W) × 76mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile) -70℃ to 120℃
- Protection rating: IP67 (solenoid)/IP65 (manifold)
- Port alignment: ISO 15407-1 compliant
- Coil insulation class: Class F (155℃)
High-density modular valve combining 4 independent 5/3-way functions in a single manifold. Features zero-pressure differential design for simultaneous multi-actuator control. Equipped with LED status indicators and manual overrides. Optimized flow paths reduce pressure drop by 18% compared to previous generation models.
- Multi-axis pneumatic robot end effectors
- Bottle capping machine sequencing systems
- Automated assembly line clamping controls
- Textile machinery tension regulation
- Food processing vacuum/pressure switching
Installation protocol:
Mount on flat surface with M5 fasteners (torque ≤1.2N·m). Maintain 20mm clearance
below manifold for tubing access. Use ISO 8573-1 Class 3 compressed air with
dew point ≥10℃ below ambient temperature. Parallel wiring recommended for multi-valve
synchronization.
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B16F |
