Airtac CPV10S Integrated Manifold Valve CPV10SJ04B24F
2. Manual override function incorporated into solenoid valves for simplified installation and system adjustment.
3. Features low actuation voltage and extended service life for enhanced operational reliability.
Category: Modular Valves | Brand: AIRTAC | Series: CPV10S
AirTAC CPV10S Integrated Valve CPV10SJ04B24F Technical Specifications
- Model: CPV10SJ04B24F
- Type: 5-port 3-position closed center (Integrated manifold base + solenoid valves)
- Port size: G1/8 (ISO228-1 standard)
- Operating pressure range: 0.2–0.8 MPa (29–116 PSI)
- Voltage: DC24V ±10% (Coil insulation class: Class F)
- Weight: 215g ±3% (including manifold base and solenoids)
- Dimensions: 52mm(W) × 34mm(H) × 98mm(L)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 1.6W (per solenoid)
- Protection rating: IP67 (Dustproof/Waterproof)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Response time: ≤15ms (On/Off)
- Manual override: Built-in emergency switch
- Port thread depth: 9mm (minimum engagement)
Modular pneumatic control solution combining manifold base and solenoid valves in a space-saving design. Features shock-resistant aluminum alloy construction with anti-vibration mounting slots. The dual-color LED status indicators enable quick troubleshooting. Requires ISO 8573-1 class 3.4.2 compressed air (max 50mg/m³ oil content).
- Multi-axis pneumatic actuator synchronization in assembly robots
- Precision clamping control for CNC rotary tables
- Vacuum cup array management in material handling systems
- Cleanroom-compatible medical device assembly lines
- High-cycle packaging machine diverters (up to 1.5 million cycles)
Installation guidelines:
Use M4×12mm stainless steel screws (1.2N·m torque limit). Maintain 15mm
clearance below manifold for tubing access. Perform air bleeding after
maintenance using the integrated purge ports.
- APV10S series pilot valves
- APET-04 pressure regulators
- ISO 15407-2 compliant quick connectors
| Property | Property Value |
|---|---|
| sku | CPV10SJ04B24F |
