Airtac CPV15S Integrated Valve Manifold CPV15S8F
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2、Features modular design with flexible expandability, allowing arbitrary combination and extension of connected solenoid valves. Optional blanking plates included for configuration flexibility.
Category: Solenoid Valve Manifold Base , Brand: AirTAC , Series: CPV15S
AirTAC CPV15S8F Modular Valve Base Specifications
- Model: CPV15S8F (CPV15S series)
- Type: Modular ISO 5599-1 compliant manifold base
- Port size: G1/8 (BSPP) × 8 ports
- Thread standard: Metric (M5 optional via adapters)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Max flow rate: 850 L/min (ANR)
- Material: Aluminum alloy (anodized surface)
- Seal type: Integrated NBR gasket matrix
- Temperature range: -5℃ to 60℃ (operating fluid)
- Weight: 520g ±5% (bare base)
- Dimensions: 98mm(L) × 42mm(W) × 32mm(H)
- Mounting pattern: 40mm modular pitch
- Compatibility: Works with CPV10/15/20 series valves
High-density modular base with 8-station capability, featuring precision-milled flow channels for minimized pressure drop. The staggered port design allows 360° manifold assembly flexibility. Includes pre-installed mounting slots for DIN rail or direct panel installation.
- Multi-valve pneumatic control stations
- Automated assembly line sequencing systems
- Textile machinery air circuit distribution
- Beverage filling plant manifold clusters
- Robotic end-effector control units
Installation note:
Apply 2.5-3.5Nm torque during valve mounting. Use Loctite 243
on sub-base connectors for permanent installations. Maximum
12-base stack recommended without auxiliary support.
| Property | Property Value |
|---|---|
| sku | CPV15S8F |
