Airtac CS1 Proximity Sensor CS1-E
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-E Inductive Proximity Switch Technical Details
- Model: CS1-E Series
- Type: Shielded inductive sensor (DC 3-wire)
- Sensing principle: Electromagnetic field variation
- Supply voltage: 10-30V DC (±10%)
- Output type: NPN NO (Normally Open) / PNP NO variants
- Detection distance: 1.5mm ±10% (Standard sensing range)
- Operating temperature: -25℃ to +70℃
- Protection class: IP67 (IEC standard)
- Housing material: Nickel-plated brass with ABS encapsulant
- Connection type: 2m PVC cable (M8 connector optional)
- Cable specification: 0.34mm² 3-core shielded
- Response frequency: 500Hz
- Weight: 85g ±3g (including cable)
- Dimensions: 18mm(D) × 34mm(L) × 10mm(W)
- Hysteresis: ≤15% of sensing distance
- Indicator: Red LED status light
High-precision non-contact sensor featuring temperature compensation circuitry for stable detection in industrial environments. The triple-shielded design minimizes electromagnetic interference, with reverse polarity protection and short-circuit prevention. Operates effectively through non-ferrous materials up to 2mm thickness.
- Position verification in pneumatic cylinder end-stops
- Object presence detection on conveyor systems
- Rotary encoder synchronization in packaging machinery
- Safety interlock systems for elevator doors
- Tool position monitoring in CNC equipment
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance, align target perpendicular to sensing face
with ≤0.5mm air gap. Clean sensing surface monthly with isopropyl alcohol.
| Property | Property Value |
|---|---|
| sku | CS1-E |
| Specification | Type E |
