Airtac CS1 Proximity Sensor CS1-G
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-G Inductive Proximity Switch Technical Details
- Model: CS1-G Series
- Detection type: Inductive (non-contact)
- Sensing distance: 1.5mm ±10% (Iron target)
- Voltage range: DC10-30V (±10% ripple)
- Current consumption: ≤15mA
- Output configuration: NPN normally open (NO) or PNP selectable
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Protection: Reverse polarity protection, short-circuit protection
- Housing material: Nickel-plated brass
- Indicator: Red LED status display
- Temperature range: -25℃ to +70℃
- Protection rating: IP67 (IEC standard)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3 axes)
- Weight: 28g ±2g
- Dimensions: 18mm(D) × 34mm(L) × 8mm(W)
High-precision inductive sensor with temperature-compensated circuitry, engineered for stable detection in rugged industrial environments. Features a flush-mountable design for space-constrained installations and includes built-in surge protection for enhanced durability. Compatible with metal targets including iron, aluminum, and stainless steel (reduction factors apply).
- Position verification in pneumatic cylinder end stops
- Conveyor belt object counting systems
- CNC machine tool position feedback
- Automated packaging equipment presence detection
- Robotic arm joint limit sensing
Installation guidelines:
Maintain 2x sensor diameter clearance between adjacent units. For optimal performance,
clean sensing face regularly using isopropyl alcohol. Avoid mounting near high-frequency
welding equipment without shielding.
| Property | Property Value |
|---|---|
| sku | CS1-G |
| Specification | G-Type |
