Airtac CS1 Proximity Sensor CS1-J
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-J Inductive Proximity Switch Technical Details
- Model: CS1-J
- Sensor type: Shielded inductive proximity sensor
- Detection distance: 2mm ±10% (standard), 3mm max (metal target)
- Output configuration: NPN normally open (NO) / PNP selectable via wiring
- Supply voltage: DC 12-24V (±10% ripple)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Stainless steel (SUS304)
- Operating temperature: -25℃ to +70℃
- Connection: 2m PVC cable (standard) / M12 connector (optional)
- Weight: 50g ±3g
- Dimensions: 40mm(L) × 15mm(W) × 15mm(H)
High-precision non-contact switch with temperature compensation circuitry, designed for harsh industrial environments. Features reverse polarity protection and short-circuit prevention. The stainless steel housing provides exceptional resistance to mechanical stress and chemical splashes. Includes status LED for operational feedback.
- Cylinder position feedback in pneumatic systems
- Conveyor belt object detection
- Machine tool safety door monitoring
- Packaging machine component alignment
- Injection molding machine clamp position sensing
Installation guidance:
Maintain 1.5x sensor diameter clearance from adjacent metal surfaces.
For optimal performance, calibrate with target material (steel/copper/aluminum)
using the built-in sensitivity adjustment screw. Avoid mounting near high-frequency
equipment without shielding.
| Property | Property Value |
|---|---|
| sku | CS1-J |
| Specification | Type J |
