Airtac CS1 Proximity Sensor CS1-M-020-A-20
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-M-020-A-20 Proximity Sensor Specifications
- Model: CS1-M-020-A-20
- Type: Inductive proximity switch (shielded)
- Detection distance: 20mm ±10%
- Output configuration: NPN normally open (NO)
- Supply voltage: 10-30VDC (±10% ripple)
- Current consumption: ≤15mA
- Response frequency: 500Hz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (Fe≥12×12×1mm)
- Connection type: 2m PVC cable (18AWG)
- Temperature range: -25℃ to +70℃
- Weight: 210g ±5g
- Dimensions: 50mm(L) × 20mm(W) × 20mm(H)
High-precision industrial proximity sensor with temperature compensation circuit, featuring anti-electromagnetic interference design. The triple-sealed structure (epoxy resin + O-ring + cable gland) ensures reliable performance in harsh environments. Requires metal mounting brackets for vibration resistance.
- Position verification in pneumatic cylinder stroke control
- Conveyor belt object counting systems
- Machine tool safety door interlocks
- Automated warehouse stacker positioning
- Robotic arm end effector alignment
Installation guidelines:
Maintain 3× detection distance between adjacent sensors. For optimal performance,
clean sensing face weekly with isopropyl alcohol and avoid mounting near
high-frequency welding equipment. Ground the metal housing when used in high-humidity environments.
