Airtac CS1 Proximity Sensor CS1-T-020-A-32
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-T-020-A-32 Inductive Proximity Switch Specifications
- Model: CS1-T-020-A-32
- Type: Cylindrical shielded inductive sensor
- Operating voltage: DC 10-30V (±10% ripple)
- Output configuration: NPN normally open (NO)
- Sensing distance: 2mm ±10% (adjustable)
- Output current: ≤200mA
- Response frequency: 1kHz
- Protection rating: IP67 (dust/water resistant)
- Housing material: PBT plastic with nickel-plated brass
- Detection face: Stainless steel (AISI 303)
- Temperature range: -25℃ to 70℃
- Connection type: 2m PVC cable with M8 connector
- Repeat accuracy: ±0.02mm
- Weight: 85g ±3%
- Dimensions: 20mm(dia) × 34mm(L) × 12mm(thread length)
- Electrical protection: Short-circuit/Reverse polarity protection
- Certification: CE, RoHS compliant
High-precision inductive proximity switch engineered for metal object detection in harsh industrial environments. Features temperature-stable oscillation circuitry with LED status indication (built-in red LED). The triple-sealed construction prevents ingress of cutting fluids and metal particles. Operates with <1ms response delay for high-speed automation applications.
- Position verification in pneumatic cylinder end stops
- Tool presence detection in CNC machining centers
- Conveyor belt object counting systems
- Elevator door position sensing
- Semiconductor wafer handling robots
- Packaging machine fill-level monitoring
Installation guidelines:
Maintain 1.5×sensor diameter clearance from adjacent metal surfaces (≥30mm).
For optimal performance, align detection face parallel to target surface with
70-90% of rated sensing distance. Avoid mounting near high-frequency welding
equipment without shielding.
- Clean sensing face weekly with isopropyl alcohol in high-contamination environments
- Use surge suppressor when controlling inductive loads >50mA
- Maximum cable bending radius: 25mm (avoid sharp bends near connector)
| Property | Property Value |
|---|---|
| sku | CS1-T-020-A-32 |
| Specification | T-Type |
