Airtac CS1 Proximity Sensor CS1-U
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-U Inductive Proximity Switch Specifications
- Model: CS1-U
- Type: Shielded cylindrical inductive sensor
- Sensing distance: 2mm ±10%
- Output configuration: NPN NO/NC or PNP NO/NC (selectable)
- Supply voltage: 10-30V DC (±10% ripple)
- Output current: ≤200mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Housing material: Stainless steel (sensing face) + PBT plastic
- Temperature range: -25℃ to +70℃ (storage: -40℃ to +85℃)
- Connection type: 2m PVC cable (M8x1 connector optional)
- Protection rating: IP67 (IEC 60529)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 500m/s² (3 axes)
- Weight: 80g ±5% (with cable)
- Dimensions: Ø12mm x 40mm (L) x 15mm (W) x 15mm (H)
High-precision non-contact switch with temperature-compensated circuitry, designed for harsh industrial environments. Features reverse polarity protection and short-circuit prevention. The stainless steel face resists mechanical wear while maintaining stable detection of ferrous/non-ferrous metals.
- Cylinder piston position feedback in pneumatic systems
- Conveyor belt object detection in packaging lines
- Tool positioning in CNC machine turrets
- Safety interlock detection in automated doors
- Liquid level sensing in metal containers
Installation guidelines:
Maintain 2x sensor diameter clearance from adjacent metal surfaces.
Use anti-rotation brackets when mounting in vibrating environments.
For optimal performance, clean sensing face weekly with isopropyl alcohol.
| Property | Property Value |
|---|---|
| sku | CS1-U |
| Specification | U-shaped |
