Airtac CS1A Reed Sensor CS1A030
2. This deceptively simple design provides robust circuit control for diverse industrial and commercial applications, ensuring reliable switching performance in electrical systems.
AirTAC CS1A Magnetic Reed Sensor CS1A030 Technical Details
- Model: CS1A030
- Type: Non-contact magnetic proximity sensor (Reed switch)
- Operating voltage: DC 5-240V (±10% ripple)
- Output type: 1NO (Normally Open) contact
- Max. switching current: 200mA
- Detection distance: 4mm ±10% (from magnet surface)
- Repeat accuracy: ±0.5mm
- Response frequency: ≤3000Hz
- Protection rating: IP67 (dust/water resistant)
- Temperature range: -25℃ to +70℃
- Housing material: PBT resin (UL94 V-0)
- Cable length: 2m standard (4-core shielded cable)
- Connection type: M8 4-pin quick disconnect
- EMC protection: 2kV surge immunity
- Mechanical life: 10⁸ operations
- Weight: 28g (sensor body only), 65g with cable
- Dimensions: 18mm(W) × 6.5mm(H) × 35mm(L)
Compact magnetic reed sensor with overmolded stainless steel blade contacts, designed for precise position detection in pneumatic cylinders. Features shock-resistant construction with bidirectional LED status indication (red/green). Requires compatible magnet (e.g., CM-18) mounted on moving actuator. Operates without power supply in passive mode.
- Cylinder position feedback in automation lines
- End-of-stroke detection in packaging machinery
- Safety interlocks in injection molding machines
- Door position sensing in elevator systems
- Pneumatic actuator status monitoring
Installation guidelines:
Mount sensor parallel to magnet path with ≤0.5mm air gap.
Use non-ferromagnetic mounting brackets.
Avoid installation near strong electromagnetic fields or welding equipment.
| Property | Property Value |
|---|---|
| sku | CS1A030 |
