Airtac DMSH Electronic Sensor DMSH-P030-W
2. Its architecture comprises four core components: a thermal sensing probe, signal processing unit, digital display module, and regulated power supply system.
3. The thermal probe utilizes high-precision fast-response thermistor arrays as its sensing element, with optimized thermal conductivity design to ensure ±0.5°C accuracy and sub-2-second response time across operating ranges.
AirTAC DMSH-P030-W Electronic Proximity Sensor Specifications
- Model: DMSH-P030-W
- Type: Shielded inductive proximity sensor (DC 3-wire)
- Detection distance: 3mm ±10%
- Output configuration: NPN normally open (NO) or PNP optional
- Supply voltage: 10-30V DC ±10% (ripple P-P ≤10%)
- Current consumption: ≤15mA
- Hysteresis: ≤15% of detection distance
- Response frequency: 1kHz
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +70℃
- Storage temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz with 1.5mm amplitude
- Shock resistance: 1000m/s² (3 times each axis)
- Weight: 32g ±2g
- Dimensions: 30mm(L) × 10mm(W) × 10mm(H)
High-precision shielded inductive sensor with embedded ASIC chip for stable detection of metallic targets. Features reverse polarity protection and short-circuit prevention. The stainless steel sensing face provides exceptional resistance to oil contamination and mechanical wear. Includes status LED for operational feedback.
- Position verification in CNC machine tooling
- Pallet presence detection in automated warehouses
- End-of-stroke detection in pneumatic cylinders
- Component counting in assembly lines
- Robotic gripper position feedback systems
Installation note:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance, use M12×1 mounting nut with 0.8-1.5N·m torque.
Compatible with DIN EN 60947-5-2 standards.
| Property | Property Value |
|---|---|
| sku | DMSH-P030-W |
