Airtac DMSH Electronic Sensor DMSH-P050
2. Its architecture comprises four core components: a thermal sensing probe, signal processing unit, digital display module, and regulated power supply system.
3. The thermal probe utilizes high-precision fast-response thermistor arrays as its sensing element, with optimized thermal conductivity design to ensure ±0.5°C accuracy and sub-2-second response time across operating ranges.
AirTAC DMSH-P050 Electronic Proximity Sensor Technical Details
- Model: DMSH-P050
- Type: Shielded inductive proximity sensor (DC 3-wire)
- Sensing distance: 5mm ±10%
- Supply voltage: 10-30V DC (ripple ≤10%)
- Output configuration: NPN NO/NC or PNP NO/NC (selectable)
- Output current: ≤200mA (short-circuit protected)
- Response frequency: 500Hz
- Hysteresis: ≤15% of sensing distance
- Ambient temperature: -25℃ to +70℃
- Protection class: IP67 (IEC 60529)
- Housing material: Nickel-plated brass
- Inductive face: PBT resin
- Cable length: 2m standard (UL2464 22AWG 3-core shielded)
- Weight: 85g ±3g
- Dimensions: 50mm(L) × 12mm(W) × 25mm(H)
- Mounting: M12×1.0 threaded barrel
- LED indicator: Red (operation status)
High-precision non-contact detection sensor with temperature compensation circuit, featuring reverse polarity protection and surge immunity. The chrome-plated brass housing provides exceptional resistance to cutting fluids and industrial chemicals. Designed for stable operation in high-vibration environments with ±15% voltage fluctuation tolerance.
- Position verification in CNC machine tool changers
- Sheet metal counting in stamping presses
- End-of-stroke detection in linear actuators
- Pallet presence sensing in automated warehouses
- Rotor position feedback in servo motors
Installation guidelines:
Maintain 2× sensor diameter clearance between adjacent units.
For metallic backgrounds, use manufacturer-supplied isolation bushings.
Perform teach-in procedure after installation by power cycling three times.
| Property | Property Value |
|---|---|
| sku | DMSH-P050 |
