Airtac DMSHS Electronic Sensor DMSHS-N030
2. Its architecture typically comprises four core components: temperature sensing probe, signal processing unit, digital display, and regulated power supply.
3. The temperature sensing probe employs one or multiple high-precision, rapid-response thermistors as its sensitive component, critically determining both output temperature accuracy and millisecond-level response speed.
AirTAC DMSHS-N030 Electronic Proximity Sensor Specifications
- Model: DMSHS-N030
- Type: Diffuse-reflective photoelectric sensor (electronic)
- Sensing distance: 30±10% mm (adjustable)
- Output type: NPN NO+NC or PNP NO+NC (configurable)
- Supply voltage: 10-30V DC (±10% ripple)
- Current consumption: ≤25mA
- Response time: ≤1ms
- Repeat accuracy: ±1% of sensing distance
- Light source: Red LED (650nm wavelength)
- Protection rating: IP67 (IEC standard)
- Housing material: PBT resin (UL94 V-0)
- Connection: 2m PVC cable (M8 connector optional)
- Weight: 85±5g
- Dimensions: 30mm(W) × 15mm(H) × 45mm(L)
- Ambient illumination: ≤3,000 lux (sunlight immunity)
- Operating temp: -25℃ to +55℃ (no icing)
- Storage temp: -30℃ to +70℃
High-precision optical sensor with background suppression technology, featuring automatic sensitivity calibration and dual output configuration. The polarized lens design minimizes false triggers from reflective surfaces. Includes overload/short-circuit protection and reverse polarity safeguard.
- Object presence detection in automated assembly lines
- Carton counting in packaging machinery
- Position verification in robotic gripper systems
- Safety interlock detection in access control
- Level monitoring in bulk material handling
Installation guidelines:
Maintain 1.5× sensing distance clearance from background surfaces.
Use M4 screws (0.7Nm torque) for mounting. Avoid direct sunlight exposure
exceeding 10,000 lux. Clean lens monthly with isopropyl alcohol.
- Use shielded cables for EMI-sensitive environments
- Enable teach-in mode for automatic threshold calibration
- Maintain 50mm minimum spacing between multiple sensors
- Pair with ATC-1040 surge protector in high-inductive loads
