Airtac DMSJ Electronic Sensor DMSJ-100
2. Its architecture comprises four key components: temperature sensing probe, signal processing unit, LCD display interface, and regulated power supply system.
3. The precision-grade sensing probe employs single or multiple high-precision rapid-response thermistors as its core sensing element, with component selection directly determining the accuracy (±0.5% F.S. typical) and millisecond-level response speed of temperature output.
AirTAC DMSJ-100 Electronic Sensor Technical Details
- Model: DMSJ-100
- Type: Non-contact inductive proximity sensor
- Sensing type: NPN/PNP NO+NC configurable
- Detection distance: 1-10mm (adjustable)
- Operating voltage: DC 10-30V (±10%)
- Current consumption: ≤15mA
- Output current: ≤200mA
- Response time: ≤1ms
- Hysteresis: ≤15% of sensing distance
- Operating temperature: -25℃ to +70℃
- Protection rating: IP67 (dust/water resistant)
- Housing material: Nickel-plated brass
- Weight: 98g ±2g
- Dimensions: 50mm(L) × 18mm(W) × 34mm(H)
- Connection: 2m PVC cable (M8 connector optional)
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3-axes)
High-precision industrial-grade sensor with dual output configuration and temperature-compensated circuitry. Features reverse polarity protection and short-circuit prevention. The ruggedized design withstands mechanical stress in harsh environments, with LED status indication for real-time monitoring.
- Position detection in CNC machine tool changers
- Sheet metal counting in stamping presses
- Conveyor belt object presence sensing
- Robotic arm end-effector alignment
- Hydraulic cylinder piston position feedback
Installation guidelines:
Maintain 2× sensing distance between multiple sensors. For metallic environments,
use 304 stainless steel mounting brackets to prevent interference. Calibrate using
the built-in potentiometer after installation.
- Operates in oil mist (ISO VG32 or lighter)
- Withstands 98% RH non-condensing humidity
- UV-resistant for outdoor applications
| Property | Property Value |
|---|---|
| sku | DMSJ-100 |
