Airtac DMSJ Electronic Sensor DMSJ-NC08
2. Its architecture comprises four key components: temperature sensing probe, signal processing unit, LCD display interface, and regulated power supply system.
3. The precision-grade sensing probe employs single or multiple high-precision rapid-response thermistors as its core sensing element, with component selection directly determining the accuracy (±0.5% F.S. typical) and millisecond-level response speed of temperature output.
AirTAC DMSJ-NC08 Electronic Proximity Sensor Technical Details
- Model: DMSJ-NC08
- Type: NPN Normally Closed inductive proximity sensor
- Sensing distance: 0.8mm ±10% (Embedded flush mount)
- Output configuration: DC 3-wire (Brown+/Blue-/Black signal)
- Supply voltage: 10-30V DC ±10% ripple
- Current consumption: ≤15mA @24V DC
- Response frequency: 1kHz
- Hysteresis: ≤15% of sensing distance
- Housing material: Nickel-plated brass with PBT housing
- Detection object: Ferrous metals (≥ST12 steel)
- Temperature range: -25℃ to +70℃ (Operation), -40℃ to +85℃ (Storage)
- Protection rating: IP67 (IEC 60529)
- Vibration resistance: 10-55Hz @1.5mm double amplitude
- Shock resistance: 500m/s² (3-axes, 3 times)
- Cable specification: 2m PUR cable (Ø4.5mm), 3-core shielded
- Weight: 68g ±2g
- Dimensions: 34mm(L) × 12mm(W) × 12mm(H) (Cylindrical M12×1 body)
High-precision inductive sensor with temperature compensation circuit, featuring anti-electromagnetic interference design (10-1500MHz, 10V/m). The stainless steel sensing face resists metal particles and coolant splash. Integrated reverse polarity protection and short-circuit prevention.
- Position verification in CNC turret tool changers
- End-of-stroke detection for pneumatic cylinders
- Sheet metal counting in stamping presses
- Conveyor belt jam detection systems
- Robotic gripper state monitoring
Installation guidelines:
Maintain 2×sensing distance clearance from adjacent metal objects.
For flush mounting, ensure target material thickness ≥1mm ferrous metal.
Use M12 locknut (included) with 10-15N·m torque for vibration-prone environments.
