Airtac DPS Electronic Digital Display Pressure Sensor DPSN1-01050
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1-01050 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1-01050
- Type: Piezoresistive sensor with digital display
- Pressure range: -0.1~1.0 MPa (compound pressure measurement)
- Accuracy: ±0.5% FS (25℃)
- Output signal: 4-20mA analog + RS485 Modbus (dual output)
- Power supply: 12-28V DC (24V nominal)
- Display resolution: 0.001 MPa (3.5-digit LED)
- Port size: G1/4" female thread (NPT optional)
- Process connection: Radial port orientation
- Weight: 280g ±5g (with mounting bracket)
- Dimensions: 96mm(W) × 48mm(H) × 62mm(D)
- Media temperature: -20℃ to 85℃
- Ambient temperature: -10℃ to 60℃
- Protection rating: IP67 (front face), IP54 (housing)
- Response time: ≤10ms (90% step response)
- Long-term stability: ≤±0.3% FS/year
- Hysteresis: ≤0.1% FS
- Wetted materials: 316L stainless steel diaphragm, FKM seals
High-visibility digital pressure transducer with dual-output capability, featuring military-grade shock resistance (100G, 11ms) and automatic temperature compensation (-10~60℃). The rotating display head allows 300° adjustment for optimal viewing angles. Includes programmable alarm thresholds with relay output capability (optional). Compatible with aggressive media when using optional PTFE seals.
- Hydraulic power unit pressure monitoring
- CNC machine tool lubrication systems
- Industrial chillers refrigerant pressure control
- Plastic injection molding machine pressure feedback
- Test bench calibration systems
- Compressed air energy monitoring
Installation guidelines:
Mount in vibration-free locations using the included anti-rotation bracket.
For liquid media, orient vertically with port downward to prevent air entrapment.
Allow 2-minute warm-up for optimal accuracy. Calibration recommended every 5,000 operating hours.
| Property | Property Value |
|---|---|
| sku | DPSN1-01050 |
