Airtac DPS Electronic Digital Display Pressure Sensor DPSN1-10030
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1-10030 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1-10030
- Type: Piezoresistive sensor with digital display
- Pressure range: 0-10 MPa (0-1450 PSI)
- Output signal: 4-20mA analog + RS485 Modbus
- Accuracy: ±0.5% F.S. (25℃ reference)
- Power supply: DC24V ±10% (2W max)
- Display resolution: 0.01 MPa
- Process connection: G1/4" female thread (NPT optional)
- Medium temperature: -20℃ to 85℃
- Ambient temperature: -10℃ to 60℃
- Protection rating: IP65 (front panel)/IP40 (housing)
- Response time: ≤10ms
- Weight: 420g ±5% (with packaging)
- Dimensions: 96mm(W) × 48mm(H) × 82mm(D)
- Housing material: Die-cast aluminum alloy (black anodized)
- Display: 4-digit LED with red backlight
- Zero/span adjustment: Front-panel tactile buttons
Industrial-grade pressure transducer featuring dual output capability and instant visual monitoring. The shock-resistant design incorporates O-ring sealed buttons and vibration-damping mounting ears. Calibration data is stored in EEPROM with 0.1% setting resolution. Compatible with hydraulic oils, compressed air, and non-corrosive gases.
- Hydraulic power unit pressure monitoring
- CNC machine tool lubrication systems
- Plastic injection molding pressure control
- Compressed air system energy audits
- Test bench data acquisition systems
- Water treatment plant pump protection
Installation guidelines:
Mount in vibration-free location using supplied bracket. Allow 50mm clearance behind sensor for cable routing.
Use 60-80% of full scale for optimal accuracy. Perform warm-up for 15 minutes before critical measurements.
| Property | Property Value |
|---|---|
| sku | DPSN1-10030 |
