Airtac DPS Electronic Digital Display Pressure Sensor DPSN1-10050
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1-10050 Electronic Digital Pressure Sensor Technical Details
- Model: DPSN1-10050
- Pressure range: -0.1~1.0 MPa (customizable 0~100MPa on request)
- Accuracy: ±0.5% F.S. (±1.0% optional for harsh environments)
- Output signals: Dual output 4-20mA + 0-10V (RS485 Modbus-RTU optional)
- Display: 4-digit LED with 360° rotatable head (0.56" digit height)
- Power supply: 12-36V DC (reverse polarity protected)
- Current consumption: ≤25mA @ 24V DC
- Response time: ≤50ms (90% step response)
- Port size: G1/4" BSPP (NPT1/4" available)
- Medium compatibility: Air, N2, Argon, hydraulic oils (ISO VG32-68)
- Temperature range: -20℃~85℃ (compensated)
- Protection rating: IP67 (submersible up to 1m for 30min)
- Housing material: Anodized aluminum alloy (304SS optional)
- Weight: 280g ±5% (with mounting bracket)
- Dimensions: 78mm(L) × 42mm(W) × 38mm(H) (excluding connector)
Industrial-grade pressure transducer with 1000Hz sampling rate and auto-zero calibration. Features shock/vibration resistance (up to 20g RMS) and 10,000hr MTBF. The dual O-ring design prevents media leakage in high-pulse applications. Display shows real-time pressure with peak hold/valley hold functions.
- Hydraulic press pressure feedback systems
- CNC machine tool lubrication monitoring
- Plastic injection molding pressure profiling
- HVAC duct static pressure measurement
- Electric vehicle brake pressure testing rigs
- Water treatment plant pump protection
Installation guidelines:
Mount in vibration-free locations using 6mm anti-shock washers.
Maintain 50mm clearance from high-current cables. Perform initial
calibration after 24hr burn-in period. Use M3 stainless steel
screws (max torque 0.8N·m) for bracket installation.
| Property | Property Value |
|---|---|
| sku | DPSN1-10050 |
