Airtac DPS Electronic Digital Display Pressure Sensor DPSN1B-01020
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1B-01020 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1B-01020
- Type: Electronic digital display pressure transducer
- Pressure range: 0-10 bar (0-145 psi)
- Output signal: 4-20mA analog + RS485 digital (Modbus RTU protocol)
- Power supply: 24V DC ±10%
- Accuracy: ±1.0% FS (25℃ reference)
- Operating temperature: -20℃ to 70℃
- Protection rating: IP67 (front face), IP65 (housing)
- Display: 4-digit LED with red backlight (0.36" digit height)
- Port connection: G1/4" BSPP female thread
- Weight: 320g ±5% (including cable connector)
- Dimensions: 78mm(W) × 40mm(H) × 62mm(D)
- Housing material: Anodized aluminum alloy (black)
- Response time: ≤10ms
- Long-term stability: ≤±0.5% FS/year
- CE & RoHS compliant
Industrial-grade pressure sensor featuring dual output capability and real-time visual monitoring. The shock-resistant housing contains a MEMS sensing element with temperature compensation, achieving 0.05% resolution. Includes programmable alarm thresholds via push-button interface. Compatible with hydraulic oils and lubricated air (ISO 8573-1 class 4).
- Injection molding machine pressure monitoring
- Pneumatic system pressure feedback control
- Industrial refrigeration compressor protection
- Water treatment plant pump pressure tracking
- CNC machine hydraulic pressure verification
- Energy management systems (EMS) data collection
Installation guidelines:
Mount in vibration-free locations using 35-45 N·m torque on port connection.
Maintain minimum 15cm clearance behind display for cable routing.
Perform zero calibration after 30-minute warm-up period.
