Airtac DPS Electronic Digital Display Pressure Sensor DPSN1B-10030
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1B-10030 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1B-10030
- Type: Piezoresistive digital display sensor
- Pressure range: -100kPa to 3MPa (compound pressure measurement)
- Output signal: 4-20mA analog + RS485 Modbus-RTU
- Supply voltage: 12-28VDC (±10% ripple)
- Accuracy: ±0.5% FS (25℃ reference)
- Display: 4-digit LED with 0.36" digit height
- Response time: ≤10ms (90% FS step change)
- Medium temperature: -20℃ to 85℃
- Ambient temperature: -10℃ to 60℃
- Process connection: G1/4" BSPP female thread
- Seal material: Fluororubber (FKM)
- Housing material: Anodized aluminum alloy
- Protection rating: IP67 (NEMA 4X equivalent)
- EMC immunity: 4kV contact discharge per IEC 61000-4-2
- Weight: 235g ±5g (with mounting bracket)
- Dimensions: 78mm(W) × 40mm(H) × 62mm(D)
High-visibility digital pressure transducer with dual output capability, featuring automatic temperature compensation and zero-point calibration. The shock-resistant housing withstands 50G acceleration (11ms duration) and includes a 360° rotatable display for flexible installation. Calibration certificates available upon request (NIST traceable).
- Hydraulic press pressure monitoring systems
- CNC machine tool lubrication monitoring
- Industrial refrigeration compressor protection
- Plastic injection molding pressure profiling
- Test bench data acquisition systems
Installation guidelines:
Mount in vibration-free locations using the included M4 mounting clips.
Avoid direct sunlight exposure and maintain ≥20mm clearance for display viewing.
Perform zero calibration after 500hrs continuous operation.
| Property | Property Value |
|---|---|
| sku | DPSN1B-10030 |
